A function signature should say what the function can do

This function reads a file:

fn load_config(path: &str) -> std::io::Result<String> {
    std::fs::read_to_string(path)
}

Its signature names the input, the output, and the failure channel. It does not name the filesystem. A caller can discover that dependency only by opening the body, following documentation, or observing the process.

capsec moves the filesystem dependency into the type boundary:

use capsec::prelude::*;

fn load_config(
    path: &str,
    cap: &impl CapProvider<FsRead>,
) -> Result<String, CapSecError> {
    capsec::fs::read_to_string(path, cap)
}

Both functions perform the same business operation: accept a path and return its contents. The second function also states a precondition. The caller must provide a value that implements CapProvider<FsRead>.

That difference is enforced at compilation, provided the implementation stays inside capsec’s typed wrappers.

The wrapper checks the target before touching `std`

The filesystem wrapper in capsec-std/src/fs.rs asks the provider for an FsRead proof against the requested path. Only after that succeeds does it call the standard library:

pub fn read_to_string(
    path: impl AsRef<Path>,
    cap: &impl CapProvider<FsRead>,
) -> Result<String, CapSecError> {
    let _proof: Cap<FsRead> =
        cap.provide_cap(&path.as_ref().to_string_lossy())?;

    Ok(std::fs::read_to_string(path)?)
}

An unscoped Cap<FsRead> always provides that proof. A scoped provider can inspect the target string and reject a path outside its scope. The same trait therefore carries two checks:

the Rust type must provide the correct permission class;
the provider may enforce a narrower runtime scope for the concrete target.

Network access follows the same structure. The implementation in capsec-std/src/net.rs requires NetConnect, checks the address, and then opens the socket:

pub fn tcp_connect(
    addr: &str,
    cap: &impl CapProvider<NetConnect>,
) -> Result<TcpStream, CapSecError> {
    let _proof: Cap<NetConnect> = cap.provide_cap(addr)?;
    Ok(TcpStream::connect(addr)?)
}

A reporting function consequently exposes its network dependency without exposing the implementation:

fn send_report(
    addr: &str,
    data: &str,
    cap: &impl CapProvider<NetConnect>,
) -> Result<(), CapSecError> {
    let mut stream = capsec::net::tcp_connect(addr, cap)?;
    stream.write_all(data.as_bytes())?;
    Ok(())
}

The caller can pass NetConnect to send_report. That token does not satisfy FsRead, NetBind, or Spawn.

The wrong capability is a type error

The repository retains a compile-fail fixture for the mismatch:

let root = capsec::root();
let net_cap = root.grant::<NetConnect>();

let _ = capsec::fs::read_to_string("/etc/passwd", &net_cap);

cargo test compiles that file and requires the compiler to reject it. The recorded diagnostic is:

error[E0277]: the trait bound
  `Cap<NetConnect>: CapProvider<FsRead>` is not satisfied

8 | capsec::fs::read_to_string("/etc/passwd", &net_cap);
  |                                            ^^^^^^^^
  | the trait `CapProvider<FsRead>` is not implemented
  | for `Cap<NetConnect>`

This failure does not depend on a string comparison between permission names. Rust searches for an implementation of CapProvider<FsRead> on Cap<NetConnect> and finds none.

The allowed relationships are explicit in cap_provider.rs. For example, FsAll may provide FsRead or FsWrite, and NetAll may provide NetConnect or NetBind:

impl_cap_provider_subsumes!(FsAll => FsRead, FsWrite);
impl_cap_provider_subsumes!(NetAll => NetConnect, NetBind);

There is no cross-family rule from NetConnect to FsRead, so the call cannot type-check.

Capability flow and bypass detectionTyped capsec calls require a matching provider before reaching the standard library. Direct standard-library calls bypass that type relation and become audit findings.

flowchart LR
  R["CapRoot"] --> FR["Cap(FsRead)"]
  R --> NC["Cap(NetConnect)"]

  FR --> LF["load_config(path, CapProvider(FsRead))"]
  LF --> FP["provide_cap(path)"]
  FP --> FS["std::fs::read_to_string"]

  NC --> SR["send_report(addr, CapProvider(NetConnect))"]
  SR --> NP["provide_cap(addr)"]
  NP --> TCP["TcpStream::connect"]

  NC -. "no matching trait implementation" .-> REJ["compiler error at load_config"]

  D["direct std call"] --> BY["filesystem or socket operation"]
  D -. "source or MIR scan" .-> AUD["cargo capsec audit finding"]

The compiler protects the typed path

Rust does not prevent a function from ignoring its capability parameter and calling std::fs::read_to_string directly:

fn load_config(
    path: &str,
    _cap: &impl CapProvider<FsRead>,
) -> std::io::Result<String> {
    std::fs::read_to_string(path)
}

The signature now advertises FsRead, but the operation did not consume a proof. A function with no capability parameter can make the same direct call. The compiler only enforces the relationship created by the capsec wrapper’s trait bound.

unsafe creates a second boundary. Cap<P> has a private constructor, but unsafe code can fabricate values by violating Rust’s normal initialization rules. FFI creates a third: the scanner can identify an extern block, but it cannot derive the behavior of foreign machine code from a Rust signature.

The repository tests these cases instead of folding them into the type-system claim:

Path	What is enforced or detected
`capsec::fs` and `capsec::net` wrappers	A matching `CapProvider<P>` is required by Rust.
Direct `std::fs`, `std::net`, environment, and process calls	The audit scanner reports known authority-bearing calls.
`unsafe` capability fabrication	Outside the safe-construction guarantee; repository tests prove that several forgery techniques succeed. The current audit categories do not generically report every `unsafe` block.
`extern` functions	The audit scanner reports the FFI boundary, not the foreign implementation’s effects.

The default audit works from Rust syntax. It resolves fully qualified calls, import aliases, and glob imports. That leaves documented blind spots, including function-pointer indirection, include!, inline assembly, generated code, and some re-export paths. Deep analysis uses compiler MIR and can recover some macro-expanded and indirect behavior, but it requires the nightly driver and still does not turn foreign code into inspectable Rust.

The resulting claim is narrower than “a function without a capability cannot perform I/O.” It also means a policy that intends to forbid unsafe code needs a separate compiler lint or audit step. The supported capsec type claim is:

A call through a capsec wrapper cannot compile unless its arguments provide the wrapper’s permission type. Direct ambient calls are audit findings; unsafe construction and other escape hatches require checks outside that trait relation.

That division gives each mechanism a check it can actually perform. Rust rejects the wrong token. The runtime provider checks the target. The audit scanner searches for known direct bypasses. A separate policy must reject unsafe code when the application cannot permit capability fabrication.

Continue through the dependency graph

A typed application boundary does not make dependency upgrades inert. A dependency update can change what your program is allowed to do follows authority-bearing calls across crate versions and through a three-crate call chain.
