A dependency update can change what your program is allowed to do

A dependency update usually arrives as a small textual change:

[dependencies]
-zip = "2.3"
+zip = "2.4"

The new version may preserve the API your application calls while changing the operations reachable behind that API. A helper can begin reading a directory, opening a socket, spawning a process, or entering foreign code without adding a new parameter to your function.

cargo capsec diff compares those operations as a separate property of the version:

cargo capsec diff zip@2.3.0 zip@2.4.2 --fail-on-new

The command fetches both published sources, scans each version, and compares the resulting findings. In this run, paths have been shortened to start at the crate’s src directory:

zip 2.3.0 → 2.4.2

+ FS  src/read/stream.rs:61  std::fs::create_dir_all  extract()
+ FS  src/read.rs:463        std::fs::File::create    make_symlink()
+ FS  src/read.rs:867        std::fs::create_dir_all  extract_internal()
+ FS  src/read.rs:922        std::fs::File::create    extract_internal()
- FS  src/read.rs:462        File::create             make_symlink()
- FS  src/read.rs:821        std::fs::File::create    extract()

Summary: 4 added, 2 removed, 6 unchanged

Because the result contains additions, --fail-on-new exits with status 1. That exit code can stop an automated update before the new source is accepted without review.

Two additions correspond to changed filesystem behavior

The output is a review queue, so each line still needs source context.

ZipStreamReader::extract exists in both versions. In 2.4.2 it begins by creating the destination directory before canonicalizing it and writing each streamed archive member:

pub fn extract<P: AsRef<Path>>(self, directory: P) -> ZipResult<()> {
    create_dir_all(&directory)?;
    let directory = directory.as_ref().canonicalize()?;

    // The visitor creates directories, files, and symbolic links
    // beneath `directory`.
    self.visit(&mut Extractor(directory, IndexMap::new()))
}

The existing archive extraction path also changes. Version 2.3.0 canonicalized the destination immediately, which required the directory to exist. Version 2.4.2 first calls create_dir_all, then canonicalizes it:

fn extract_internal<P: AsRef<Path>>(
    &mut self,
    directory: P,
    root_dir_filter: Option<impl RootDirFilter>,
) -> ZipResult<()> {
    create_dir_all(&directory)?;
    let directory = directory.as_ref().canonicalize()?;
    // ...
}

The changelog describes this as “Create directory for extraction if necessary.” From an API perspective it is a bug fix. From an authority perspective it adds a filesystem write: calling extraction can now create the destination directory instead of failing when that directory is absent.

The other two added lines require a different interpretation. File::create in make_symlink became std::fs::File::create, and extract() was refactored into extract_internal(). The diff engine matches findings by:

(
    finding.function,
    finding.call_text,
    finding.category,
)

Line numbers are intentionally excluded, so ordinary line movement does not create an addition. Function renames and changes in call spelling do create one. The paired additions and removals around File::create therefore describe source restructuring, not four wholly new filesystem powers.

The two create_dir_all findings remain useful after that classification: one records the changed stream-extraction path; the other records the same destination-creation behavior in extract_internal.

An authority profile is a set of observed operations

For a crate version (v), define its scanned authority profile as:

A(v) = \left\{ (\text{function},\ \text{call},\ \text{category}) \mid \text{the scanner reports that call in } v \right\}.

The positive difference is:

\Delta^+ = A(v_{\mathrm{new}}) \setminus A(v_{\mathrm{old}}).

cargo capsec diff prints (\Delta^+), the removed set, and the number of unchanged keys. It currently recognizes filesystem, network, environment, process, and FFI categories.

This profile is not the operating system’s permission table. It is evidence from source analysis under one scanner configuration. Conditional compilation may place platform-specific code in the source even when the current target does not compile it. A finding may sit in a test, behind a feature, or in an unreachable function. Conversely, syntax-level analysis has documented blind spots around some generated and indirect calls.

The diff therefore answers a bounded question:

Which authority-bearing call sites does the scanner observe in the new source that it did not match in the old source?

It does not answer whether the update is malicious, whether every addition is reachable from this application, or whether two syntactically different findings represent different behavior.

Authority propagates through ordinary calls

The direct call can be several crates below the application. capsec retains a three-crate fixture for this case:

// app/src/lib.rs
pub fn handler() -> Vec<u8> {
    mid::fetch()
}

// mid/src/lib.rs
pub fn fetch() -> Vec<u8> {
    let _stream = leaf::connect().unwrap();
    vec![1, 2, 3]
}

// leaf/src/lib.rs
pub fn connect() -> std::io::Result<TcpStream> {
    TcpStream::connect("127.0.0.1:8080")
}

Only leaf::connect names the socket operation. With dependency propagation enabled, the scanner first records Net on the leaf’s exported function. It then treats that export as an authority-bearing call while scanning mid, and repeats the process while scanning the application. The integration test requires both mid::fetch and app::handler to receive cross-crate network findings.

Network authority across three cratesThe application reaches TcpStream::connect through two ordinary function calls. Dependency export maps propagate the network finding back to each public caller.

flowchart LR
  A["application::handler"] --> M["mid::fetch"]
  M --> L["leaf::connect"]
  L --> T["TcpStream::connect"]

  T -. "direct NET finding" .-> L
  L -. "exported authority" .-> M
  M -. "exported authority" .-> A

The version diff and dependency propagation answer related but distinct questions:

Command	Question
`cargo capsec diff crate@old crate@new`	Which scanned call sites changed between two versions of one crate?
`cargo capsec audit --include-deps`	Which authority categories propagate from dependencies into this workspace’s callers?

A lockfile update can be checked at both levels. First compare the changed crate versions. Then scan the resolved dependency graph to see which findings reach application code:

cargo capsec diff zip@2.3.0 zip@2.4.2 --format json
cargo capsec audit --include-deps --fail-on high

The first command produces structured evidence for the update. The second applies the workspace’s severity threshold to the resolved graph. Neither replaces source review; they select the paths where review has a concrete authority change to explain.

Continue at the function boundary

Dependency analysis finds ambient operations after they enter the graph. A function signature should say what the function can do shows the complementary mechanism: require filesystem and network authority at the Rust call boundary, then use audit to detect direct calls that bypass it.
