The repository rejects reverse dependencies

auths-proof keeps its verifier in the same monorepo as transports, product integrations, language bindings, and demos. That arrangement makes protocol changes atomic, but it also makes an invalid import easy to write.

The repository handles that risk with two machine-readable contracts:

• architecture.toml classifies every package and defines which layer it may depend on;
• core/spec/v1/auths-proof.cddl defines the bytes that every implementation must accept and produce.

cargo xtask arch compares both policy and repository state. A package in the wrong directory, an unclassified crate, a reverse dependency, a dependency cycle, an unapproved build script, or drift in the committed graph makes the command fail.

Dependencies move toward the kernel

The shipping layers are ordered:

flowchart RL
  D["demos<br/>integration + benchmarks"] --> B["bindings<br/>WASM + Python"]
  D --> P["product<br/>profiles + runtime + state"]
  D --> E["exchange<br/>proof transport"]
  D --> C["core<br/>offline semantics"]
  B --> P
  B --> E
  B --> C
  P --> E
  P --> C
  E --> C
  X["xtask<br/>non-shipping control plane"] -. "inspects all layers" .-> C

The policy records the direction explicitly:

[layers.core]
path = "core/"
allowed_dependencies = ["core"]

[layers.exchange]
path = "exchange/"
allowed_dependencies = ["core", "exchange"]

[layers.product]
path = "product/"
allowed_dependencies = ["core", "exchange", "product"]

[layers.bindings]
path = "bindings/"
allowed_dependencies = ["core", "exchange", "product", "bindings"]

This gives the directories semantic meaning.

• core owns deterministic protocol semantics and effect-free ports.
• exchange moves proofs but cannot redefine their validity.
• product adds profiles, state, execution, receipts, stores, and integrations.
• bindings expose existing behavior to other languages.
• demos may exercise all shipping layers, but no shipping package may depend on a demo.

If the HTTPS adapter imports a core model type, the edge points toward the kernel and passes. If auths-verifier imports reqwest, the edge either names a higher layer or a forbidden external capability and fails.

xtask reads the actual Cargo graph

The check does not search source text for suspicious names. It runs cargo metadata, obtains every resolved workspace package and dependency, and compares the result with architecture.toml.

The first equality prevents undocumented packages:

let workspace_names: BTreeSet<String> = packages
    .iter()
    .map(package_name)
    .collect::<Result<_, _>>()?;

let classified: BTreeSet<_> =
    policy.packages.keys().cloned().collect();

if workspace_names != classified {
    return Err(format!(
        "architecture package classification drift; \
         missing={missing:?}, stale={stale:?}"
    ));
}

For each dependency edge, the check resolves both package layers:

if let Some(dependency_layer) = dependency_layer {
    if !layer.allowed_dependencies.contains(dependency_layer) {
        return Err(format!(
            "forbidden {layer_name} -> {dependency_layer} dependency: \
             {name} -> {dependency_name}"
        ));
    }
}

Core also has a capability denylist containing async runtimes, web frameworks, network clients, databases, key stores, and hosted SDKs. Entries include tokio, reqwest, iroh, axum, sqlx, keyring, and git2.

That second check matters because an external crate has no internal layer label:

if layer_name == "core"
    && dependency_layer.is_none()
    && policy.core_forbidden_dependencies
        .iter()
        .any(|name| dependency_matches(name))
{
    return Err(format!(
        "core capability dependency is forbidden: \
         {package} -> {dependency}"
    ));
}

The command also checks:

The current exception table is empty. If an exception is added, load_architecture_policy validates its owner, reason, issue, and expiry, then fails because expiry enforcement has not been implemented. An exception cannot silently weaken the graph.

The offline boundary follows from the graph

The architecture rule produces a concrete property: the verifier cannot acquire facts.

VerifierContext contains the values that applications often read imperatively:

pub struct VerifierContext {
    configuration: VerifierConfigurationId,
    composition: CompositionRequirement,
    trust_anchors: Vec<TrustAnchor>,
    accepted_registries: AcceptedRegistries,
    expected_audience: Audience,
    expected_challenge: Challenge,
    evaluation_time: Timestamp,
    assurance_policy: AssurancePolicy,
    principal_status_snapshot: PrincipalStatusSnapshot,
    grant_status_snapshot: GrantStatusSnapshot,
    resource_matcher: ResourceMatcherId,
    profile_policy: ProfilePolicyId,
    channel_policy: ChannelBindingId,
    limits: VerifierLimits,
}

There is no Clock, HttpClient, Database, or Resolver field. Live code outside core obtains facts and packages them into immutable evidence or context. The same proof, action, context, and executable registry configuration must therefore produce the same result in native Rust and WASM.

Signed meaning requires one byte representation

The architecture constrains code dependencies. Deterministic CBOR constrains wire interpretation.

Two byte strings can represent the same abstract CBOR value. That flexibility is unacceptable when one machine signs bytes and another verifies them. V1 therefore admits one encoding for each protocol value.

ADR 0002 fixes the decisions:

• integer map keys;
• fixed map shapes;
• definite lengths;
• minimal integer encodings;
• sorted, duplicate-free sets;
• no unknown critical keys;
• no trailing bytes.

The CDDL is the wire authority. Rust struct layout is not.

The grant schema exposes every attenuation dimension with exact keys:

grant-statement = {
  0: protocol-version,
  1: principal-id,
  2: principal-id,
  3: profile-id,
  4: profile-version,
  5: permission-set,
  6: timestamp,
  7: timestamp,
  8: audience-set,
  9: action-constraint,
  10: budget-ceiling / null,
  11: uint .le 65535,
  12: digest32 / null,
  13: status-policy,
  14: bounded-id,
  15: critical-extensions,
}

Because the map must contain exactly these keys in this order, a decoder cannot ignore a field that another implementation treats as meaningful.

The decoder proves canonicality by reconstruction

The Rust decoder first applies structural and deployment bounds. After decoding the typed object, it re-encodes that object and compares the result with the original bytes:

pub fn decode_bundle(
    input: &[u8],
    limits: &VerifierLimits,
) -> Result<ProofBundle, CodecError> {
    limits.validate()?;

    if input.len() > limits.get(LimitKind::BundleBytes) {
        return Err(CodecError::LimitExceeded);
    }

    let mut decoder = Decoder::new(input);
    let bundle = bundle_from(&mut decoder, limits)?;
    ensure_complete(&decoder, input)?;

    if encode_bundle(&bundle)?.as_slice() != input {
        return Err(CodecError::NonCanonical);
    }

    Ok(bundle)
}

A non-minimal integer can decode to the same number, but reconstruction emits the minimal form. The byte comparison rejects the original. Appending one extra CBOR value fails ensure_complete.

The test suite retains both cases:

#[test]
fn equivalent_non_minimal_integer_is_rejected() { /* ... */ }

#[test]
fn trailing_data_is_rejected() { /* ... */ }

Bounds are part of the protocol

The CDDL records hard maxima before a verifier allocates or calls an adapter:

• proof bundle: 8 MiB;
• grants: 256;
• plan leaves: 128;
• plan depth: 16;
• evidence objects: 512;
• one evidence object: 2 MiB;
• signatures: 1,024;
• total work units: 1,000,000.

Deployments may choose lower values in VerifierContext. A proof cannot raise them.

Adapter work is reserved before execution. A KERI history, signature check, resource matcher, or policy handler must declare a conservative maximum and report the work it consumed. Exceeding the configured total returns ResourceLimitExceeded.

The repository therefore constrains two graphs:

1. the build graph cannot make the offline kernel depend on higher-layer capabilities;
2. the proof graph cannot make verification exceed explicit byte, depth, collection, or work limits.

Part one introduces the authorization model: Authority should only get smaller.

Part three follows the replaceable interfaces on either side of the kernel: One authority model, many identity and transport systems.
