A proof should break when the program changes

A formal model can be correct while the program is wrong.

That sentence is not an objection to formal methods. It is the reason I care about the boundary between a formal model and production code.

Suppose I write a clean Lean definition of delegation, prove that authority only attenuates, and then implement the verifier separately in Rust. The Lean theorem may be valid. The Rust test suite may be green. Neither fact, by itself, establishes that the Rust evaluator implements the relation I proved. The two artifacts can disagree because I misunderstood one of them, because a later refactor changed only one, or because they chose different answers for a small case such as an absent budget or the first diagnostic returned after several checks fail.

For Auths Proof, I wanted a stronger maintenance property:

The formal layer should not be an illustration that remains green beside a changing program. It should be connected tightly enough to production that a semantic change can invalidate the connection. Continuous integration should then refuse the change until the generated translation, the refinement proof, and the declared assurance claim agree again.

This post explains the mechanism we use to approach that property. Charon extracts a representation of selected production Rust. Aeneas translates that representation into executable Lean definitions. Handwritten Lean semantics state the authority relation in mathematical terms. Refinement theorems connect the generated evaluator to those semantics. CI reproduces the translation, audits theorem statements and axioms, checks source closure, and runs several lower-level bridges around the proof.

It is a deliberately bounded claim. We are not proving all of Auths Proof, all of Rust, or all of authorization. We are proving particular properties about particular production functions over validated values, under an explicit toolchain and representation boundary.

The property is attenuation

The core authority rule is simple to say:

A delegation may preserve or reduce authority. It may not expand it.

An authority scope contains more than a permission name. In the current rich model, a scope $S$ contains:

where:

• $P$ is the profile scope;
• $M$ is a finite set of permissions;
• $W = [s,e]$ is an inclusive validity window;
• $A$ is a finite set of audiences;
• $C$ is a constraint over canonical action-body digests;
• $B$ is an optional budget ceiling;
• $T$ is a status policy; and
• $Q$ is an assurance policy.

For a proposed child scope $S_c$ and its parent $S_p$, structural attenuation is a conjunction:

Delegation adds chain and depth conditions. If $G$ is the proposed grant and $\Sigma_p$ is the parent chain state, then an accepted edge requires:

and:

These are not only predicates used to accept or reject a grant. They determine the unique accepted next state. The root remains unchanged, the subject becomes the grant subject, the accepted scope becomes the grant’s attenuated scope, the depth becomes $d_c$, and the terminal grant identifier becomes the new grant identifier.

The Lean semantics say this directly:

def delegates
    (parent : ChainState v)
    (grantId : GrantId v)
    (grant : Grant v)
    (child : ChainState v) : Prop :=
  linked parent grant ∧
  ∃ checks : scopeDepthChecks parent grant,
    child = acceptedNextState parent grantId grant checks

This definition is useful because it is small enough to reason about. It is not sufficient because the shipping verifier does not execute this Lean definition.

An independent proof can prove the wrong program

Consider a narrow example. A parent allows read and refund, while a child asks only for refund. The intended relation is:

A Rust implementation can accidentally reverse the arguments:

// Wrong: asks whether the parent is a subset of the child.
permission_set_is_subset(parent.permissions, child.permissions)

The handwritten Lean theorem about $M_c \subseteq M_p$ remains true. It says nothing about the typo unless some bridge connects the actual Rust expression to the Lean expression being proved.

Why aren’t unit tests enough?

Unit tests are necessary. They are not the same kind of claim as a proof.

Imagine a guard who decides whether one person may pass a locked door. We test the guard with Alice, Bob, and Carol. The guard gives the right answer three times. We have learned something useful: those three examples work, the test harness can reach the guard, and later changes can be compared with those answers.

We have not learned the rule the guard will apply to the next person.

A unit test fixes one input $x_i$, runs the program $R$, and compares the observed result with an expected result $S(x_i)$:

A suite with $n$ cases establishes that equality for a finite test set:

and, if every test passes:

The conclusion is limited to $T$. It does not imply the corresponding statement over the complete valid domain $\mathcal V$:

The gap is $\mathcal V \setminus T$: every valid case that the suite did not run. A larger suite makes $T$ larger, but a finite collection of examples does not become a universal statement merely because it contains many examples.

Authority decisions make that gap difficult to inspect manually because one input contains several interacting dimensions. A grant compares profile, permissions, validity, audiences, body constraints, budget, delegation depth, status, and assurance. It also checks issuer and parent-grant linkage. If we gave only three boundary categories to each of ten checks, the cross-product would already contain:

combinations.

Lean does not enumerate those $59{,}049$ combinations one by one. The refinement theorem proves a universal statement: for every valid input combination represented by the authority model, the mechanically translated production evaluator returns the result required by the rich specification. The real domain is much larger than this illustration because it contains sets, identifiers, intervals, optional values, and ordered diagnostics.

That statement applies to the selected authority-kernel functions and their explicit valid-input domain. It does not mean that Lean proves every Auths component works for every possible input. Decoding, cryptography, storage, networking, and application adapters remain outside this refinement theorem and require their own evidence.

The number therefore illustrates why sampled coverage becomes difficult; it is not the mechanism of the proof. Adding one test for each individual check does not cover every way in which two or more checks can interact.

The reversed-subset bug shows the problem with familiar examples. Suppose the test suite contains:

Both subset directions are true in that case:

The incorrect implementation therefore passes. A test with a strict subset would expose the defect, but someone must think to write it. A theorem about the translated function forces the subset relation to hold for every well-formed parent and child permission set in the modeled domain, including the strict cases we did not enumerate.

Tests have another limitation: the expected answer is code or data written by a person. The test and implementation can share one misunderstanding.

For example, suppose a parent has a budget ceiling and a child omits its ceiling. If both the implementation and its unit test interpret absence as “inherit the parent ceiling,” the test passes. If the protocol actually interprets absence as “unbounded,” the child has expanded its authority. The formal specification makes the cases explicit:

The refinement theorem then checks that the mechanically translated production evaluator implements those cases for all values satisfying the representation premises. The theorem can still be wrong in a broader sense if the specification states the wrong policy, but changing or reviewing one explicit relation is different from inferring the policy from hundreds of expected outputs.

Integration tests answer a further question that the refinement theorem does not claim to answer. They check whether decoding, signature verification, registry selection, the authority evaluator, storage, and an application adapter work together. If a valid grant is decoded incorrectly before it reaches the proved function, the refinement theorem does not repair the decoder. If an authorized result is mapped to the wrong Stripe operation afterward, the theorem does not repair the adapter.

The layers therefore make different statements:

Removing the tests would leave codecs, cryptography, adapters, and deployment behavior underchecked. Removing the refinement theorem would return the authority kernel to a finite sample of a large interacting domain. Auths Proof uses both because they remove different kinds of uncertainty.

So the actual answer is:

• Unit tests catch local regressions and concrete boundary cases.
• Integration tests catch disagreement between components.
• Mutation tests show that required defects are observable.
• Kani checks bounded Rust properties symbolically.
• Lean proves general semantic properties.
• Charon and Aeneas connect those proofs to the production Rust evaluator.
• CI prevents that connection from silently becoming stale.

First, make the decision translatable

The original production methods mixed comparisons, control flow, and mutation of the accumulated authority state. That shape was difficult to translate and made the proof boundary hard to name.

We reshaped the authority kernel into total, safe functions over lossless borrowed views. The public behavior did not need to change. The shipping methods now call pure evaluators, then structurally commit an accepted result or map a denial.

The delegation evaluator has this production signature:

pub fn evaluate_grant_view<'grant>(
    parent: AuthorityStateView<'_>,
    grant_id: GrantId,
    grant: GrantAuthorityView<'grant>,
) -> DelegationEvaluation<'grant>

Inside it, the Rust code computes every attenuation dimension, checks linkage first, selects a stable denial, and constructs the accepted transition:

let checks = AttenuationChecks {
    root_preserved: true,
    depth_decreases:
        parent.remaining_depth > 0
        && grant.remaining_depth < parent.remaining_depth,
    profile_attenuates:
        selected_profile_attenuates(
            parent.profile,
            parent.allowed_profiles,
            grant.profile,
        ),
    permissions_attenuate:
        permission_set_is_subset(
            grant.permissions,
            parent.permissions,
        ),
    validity_attenuates:
        validity_window_contains(
            parent.validity,
            grant.validity,
        ),
    audiences_attenuate:
        audience_set_is_subset(
            grant.audiences,
            parent.audiences,
        ),
    action_constraint_attenuates:
        action_constraint_attenuates(
            grant.action_constraint,
            parent.action_constraint,
        ),
    budget_attenuates:
        optional_budget_attenuates(
            grant.budget_ceiling,
            parent.budget_ceiling,
        ),
    status_attenuates:
        status_policy_attenuates(
            grant.status_policy,
            parent.status_policy,
        ),
    assurance_attenuates:
        assurance_policy_id_equal(
            grant.assurance_floor,
            parent.assurance_policy,
        ),
};

This shape matters for more than tooling convenience. It puts the complete decision surface inside one function:

The diagnostic $r$ and the accepted state $\Sigma_c$ are part of the result. Proving only a Boolean such as “all checks passed” would leave the failure order and state transition outside the claim.

The same pattern is used for pre-signing author scope and terminal action coverage. evaluate_author_scope_view returns the first authority dimension that failed. evaluate_action_coverage_view checks actor and terminal-grant linkage, profile selection, permission membership, validity containment, audience membership, body constraints, and requested-budget coverage in the same order used by production.

Charon records what Rust means here

Charon is a custom Rust compiler driver used by Aeneas. It starts from Rust’s Mid-level Intermediate Representation and produces LLBC, a structured representation suited to translation. The Aeneas project description describes the intermediate stages as ULLBC followed by control-flow reconstruction into LLBC.

For Auths Proof, Charon is the connection to the selected shipping source. It does not read a second, proof-only Rust implementation. The qualification manifest identifies exact production symbols from auths-model, auths-algebra-kernel, and auths-authority. Translation uses shipping features and rejects an extraction-only semantic configuration.

flowchart LR
  R["Shipping Rust<br/>pure authority evaluators"]
  M["rustc MIR"]
  C["Charon<br/>ULLBC → structured LLBC"]
  L["Pinned LLBC<br/>selected source closure"]
  A["Aeneas<br/>functional translation"]
  G["Generated Lean evaluator<br/>executable production behavior"]
  T["Refinement theorem"]
  S["Handwritten rich Lean spec<br/>sets + intervals + relations"]
  R --> M --> C --> L --> A --> G --> T
  S --> T
  R -. "called by shipping verifier" .-> X["Delegation and coverage decisions"]
  T --> Q["Audited assurance claim"]

The source closure is part of the evidence. It covers the translated dependency graph, the relevant manifests, the translation configuration, and the scripts that operate the pipeline. If one of those inputs changes while the checked-in translation remains old, the closure digest changes and the gate fails before installing the expensive formal toolchain.

This answers one form of drift: the generated evaluator cannot silently remain attached to an earlier production source closure.

Aeneas produces a functional Lean evaluator

Aeneas translates the LLBC program into a pure functional model and can emit several proof-assistant backends, including Lean. Its intended input is safe, sequential Rust within its supported subset. That limitation is one reason to isolate the authority kernel instead of attempting to translate networking, storage, provider SDKs, and every verifier concern at once.

For the Rust author-scope evaluator:

pub fn evaluate_author_scope_view(
    parent: ScopeAuthorityView<'_>,
    child: ScopeAuthorityView<'_>,
) -> AuthorScopeDecision {
    if !profile_ref_equal(child.profile, parent.profile) {
        return AuthorScopeDecision::Denied(
            AuthorityDimension::Profile,
        );
    }
    if !permission_set_is_subset(
        child.permissions,
        parent.permissions,
    ) {
        return AuthorScopeDecision::Denied(
            AuthorityDimension::Permissions,
        );
    }
    // validity, audiences, constraints, budget,
    // depth, status, and assurance follow
    AuthorScopeDecision::Accepted
}

Aeneas generates a Lean function with the same ordered computation:

def evaluate_author_scope_view
  (parent : auths_model.ScopeAuthorityView)
  (child : auths_model.ScopeAuthorityView) :
  Result AuthorScopeDecision := do
  let profileOk ←
    auths_model.profile_ref_equal
      child.profile parent.profile
  if profileOk then
    let permissionsOk ←
      auths_model.permission_set_is_subset
        child.permissions parent.permissions
    if permissionsOk then
      -- validity, audiences, constraints, budget,
      -- depth, status, and assurance follow
      ...
    else
      ok (AuthorScopeDecision.Denied
        AuthorityDimension.Permissions)
  else
    ok (AuthorScopeDecision.Denied
      AuthorityDimension.Profile)

The generated definition is intentionally not rewritten to look like the handwritten specification. Its nested if structure preserves the behavior that was extracted, including the first-failure order. That makes it less pleasant as the primary mathematical definition and more valuable as evidence about production.

The translation also makes external semantics visible. Calls into local Auths crates are linked to separately translated definitions rather than treated as opaque assumptions. The qualification currently has one reviewed standard-library bridge of semantic importance: converting a Rust string to its exact UTF-8 bytes on the validated Auths string domain. External templates may contain placeholders, but only compiled bridge modules count as evidence; the compiled import closure is required to contain no external axioms.

The handwritten model says what we intend

The rich Lean model does not care whether an identifier is stored as a Rust String, a byte array, or some future representation. It introduces opaque carriers for principals, profiles, permissions, audiences, digests, budget algebras, status methods, assurance policies, and grant identifiers.

Sets are mathematical finite sets. Validity is an inclusive interval with a proof that its start does not exceed its end. A selected profile carries a proof that it belongs to the root-allowed set. This makes the semantic model small and rules out invalid states that production constructors already reject.

For example, interval containment is:

def windowContained
    (child parent : InclusiveWindow) : Prop :=
  parent.start ≤ child.start ∧
  child.finish ≤ parent.finish

Optional budget attenuation is deliberately asymmetric:

def budgetLe
    (child parent : Option (BudgetCeiling v)) : Prop :=
  match child, parent with
  | _, none => True
  | none, some _ => False
  | some child, some parent =>
      child.algebra = parent.algebra ∧
      child.value ≤ parent.value

In mathematical notation:

An absent parent ceiling means the authority model imposes no budget ceiling, so any child ceiling attenuates it. An absent child under a bounded parent would remove the bound, so it is rejected. Writing the cases explicitly keeps that meaning out of comments and intuition.

Action constraints form another small order. Any constraint attenuates anyBody; an exact digest can attenuate the same exact digest or a set that contains it; one allowed set can attenuate another by subset; the remaining combinations fail:

These definitions express the intended order independently of the nested branches generated from Rust. The connection is supplied by refinement.

Refinement connects execution to meaning

Let:

• $R(x)$ be the Aeneas-generated Lean execution of the production Rust evaluator;
• $S(x)$ be the decision computed from the handwritten rich semantics; and
• $V(x)$ state the production representation invariants.

The central shape of the claim is:

For pre-signing scope, the checked Lean theorem says that the mechanically translated evaluator returns exactly the rich decision, including the first failing dimension:

theorem translated_rust_refines_rich_spec
    (parent child : auths_model.ScopeAuthorityView)
    (parentValid : ScopeAuthorityViewValid parent)
    (childValid : ScopeAuthorityViewValid child) :
    auths_authority.evaluate_author_scope_view parent child
      ⦃ result =>
        result = richAuthorScopeDecision
          parent child parentValid childValid ⦄ := by
  -- Each translated leaf predicate is connected to
  -- its extensional set, interval, or equality meaning.
  ...

There are corresponding theorems for terminal action coverage and delegation:

theorem translated_coverage_refines_rich_spec
    (root : Auths.Rich.Principal ProductionVocabulary)
    (authority : auths_authority.AuthorityStateView)
    (action : auths_model.ActionAuthorityView)
    (authorityValid : AuthorityStateViewValid authority)
    (actionValid : ActionAuthorityViewValid action) :
    auths_authority.evaluate_action_coverage_view authority action
      ⦃ result =>
        result = productionCoverageDecision
          (Auths.Rich.evaluateCoverage
            (richAuthorityState root authority authorityValid)
            (richAction action actionValid)) ⦄ := by
  ...

theorem translated_delegation_refines_rich_spec
    (root : Auths.Rich.Principal ProductionVocabulary)
    (parent : auths_authority.AuthorityStateView)
    (grantId : auths_model.GrantId)
    (grant : auths_model.GrantAuthorityView)
    (parentValid : AuthorityStateViewValid parent)
    (grantValid : GrantAuthorityViewValid grant) :
    auths_authority.evaluate_grant_view parent grantId grant
      ⦃ result =>
        result.outcome = productionDelegationOutcome
          (Auths.Rich.evaluateGrant
            (richAuthorityState root parent parentValid)
            (richGrantId grantId)
            (richGrant grant grantValid))
          grantId grant ⦄ := by
  ...

The notation ⦃ result => ... ⦄ is Aeneas’ result specification. The theorem does not assert that an independently written Rust-like function resembles the specification. It reasons about the generated function named auths_authority.evaluate_grant_view, whose source annotation points back to the production Rust function.

The delegation theorem is stronger than an accepted/rejected equivalence. It also equates the accepted production transition with the field projection of the rich accepted next state. A verifier that made the correct decision but wrote the wrong subject, budget, depth, or terminal grant would not satisfy that result equality.

The theorem inventory is executable policy

A theorem name in documentation is not enough. It can be renamed, weakened, deleted, or rebuilt on an unreviewed axiom while a loose CI command continues to succeed.

Auths Proof therefore has an assurance manifest. Each public claim records:

• a stable claim identifier and human-readable claim;
• the exact Lean declaration;
• a digest of the theorem statement;
• the Rust symbols to which it applies;
• the semantic source closure;
• the evidence artifacts;
• the allowed transitive axiom set; and
• residual assumptions and excluded scope.

A compiled Lean audit looks up every declaration in the environment, prints its elaborated statement, and asks Lean to collect its transitive axioms. The Rust-side audit then compares that output with the manifest.

For a claimed theorem $t$, the gate effectively checks:

The exact allowed foundational set is declared per theorem. sorryAx is not allowed. A proof replaced by sorry therefore cannot satisfy a public assurance claim merely because Lean emitted an object file.

This distinction matters because the pinned Aeneas runtime contains a small inventory of upstream sorry declarations in general slice and string iterator support. They are visible and reviewed, but none may become a transitive dependency of the claimed Auths theorems. The assurance audit enforces that boundary from the compiled environment rather than relying on a text search.

CI reproduces the bridge

The expensive gate does more than run lake build.

It first checks source closure using the ordinary Rust toolchain. If the checked-in closure does not describe the current relevant source graph, CI fails before downloading and building Charon, Aeneas, Lean, and Kani.

When translation is required, CI installs the pinned toolchain, translates the selected production functions twice in clean output directories, and requires the two generated trees to be byte-identical:

Here $S$ is the exact source closure and $\tau$ is the exact translation toolchain and configuration. CI then requires the reproduced result to equal the committed evidence:

Translation warnings are errors. Ambient compiler flags and Cargo variables that could alter semantics are rejected. The qualification manifest requires zero opaque local functions and inventories every external model. Generated Lean import closures are compiled in the same pinned environment.

After translation, CI builds the handwritten and generated Lean modules, runs the theorem and axiom audit, regenerates formal vectors, checks the Rust refinement harness, runs a required semantic mutation matrix, and applies Kani to the bounded Rust kernels used at lower bridges.

flowchart TD
  D["Pull request diff"]
  P{"Fail-closed CI planner"}
  U["Unrelated to formal closure"]
  R["Formal translation required"]
  S{"Cheap source-closure check"}
  I["Install exact pinned<br/>Rust + Charon + Aeneas + Lean + Kani"]
  T1["Translate clean tree A"]
  T2["Translate clean tree B"]
  E{"A = B = committed output"}
  L["Build generated + handwritten Lean"]
  A["Audit exact statements,<br/>source closure, and transitive axioms"]
  V["Check Lean-generated vectors,<br/>mutation matrix, Rust harness, and Kani"]
  G{"Stable formal-translation gate"}
  F["Fail"]
  D --> P
  P -->|"recognized safe skip"| U --> G
  P -->|"relevant or uncertain"| R --> S
  P -->|"malformed / unknown"| F
  S -->|"stale"| F
  S -->|"current"| I
  I --> T1
  I --> T2
  T1 --> E
  T2 --> E
  E -->|"different"| F
  E -->|"identical"| L --> A --> V --> G
  A -->|"missing / weakened / new axiom"| F
  V -->|"bridge mismatch"| F

The planner exists because a clean Aeneas reproduction is materially more expensive than an ordinary formatting or unit-test job. Selective execution is safe only if uncertainty means “run,” not “skip.” Unknown paths, malformed diffs, incomplete package graphs, and invalid manifests therefore fail closed.

The final formal-translation job is always present even when the implementation job is safely skipped. Branch protection can require one stable check name. That check succeeds only if the planner succeeded and either:

This prevents a conditional workflow from disappearing precisely when its classification logic is broken.

Why vectors, mutation checks, and Kani still matter

The formal system contains several bridges, and each tool addresses a different failure mode.

Lean generates concrete state vectors that Rust consumes. This checks that serialization and projection code around the mathematical result agree on representative boundaries. Kani symbolically checks bounded Rust kernels such as the generated conjunction over attenuation dimensions. The mutation matrix requires specified semantic defects—reversed subset checks, widened intervals, incorrect absence handling, changed diagnostic order, or omitted dimensions—to be detected by the combined refinement evidence.

These checks do not make the theorem more universal. They make the surrounding engineering claim more difficult to satisfy accidentally.

One useful way to state the layers is:

where $\mathcal V$ is the valid representation domain named by the refinement theorem, $\mathcal B$ is a bounded symbolic domain, and $\mathcal E$ is a finite regression set. Treating those sets as identical would overstate what any one check establishes.

What is inside the claim

The current production refinement covers three decision boundaries over validated model views:

1. pre-signing scope evaluation, including the first failing authority dimension;
2. terminal action coverage, including linkage, profile, permission, interval, audience, body constraint, budget, and diagnostic order; and
3. delegation, including linkage, all attenuation dimensions, denial selection, and the accepted transition fields.

The domain premise is important. Rust constructors establish facts such as:

• strings are non-empty and protocol-bounded;
• permission and audience collections are non-empty, bounded, sorted, and duplicate-free;
• inclusive validity windows are well formed;
• freshness limits are non-zero;
• profiles are valid; and
• borrowed authority views preserve every field consumed by the evaluator.

The refinement theorems assume those representation invariants. Aeneas erases private Rust newtype constructors into Lean carriers, so arbitrary Lean values of the carrier type are not automatically values that safe production Rust can construct.

If $\mathcal R$ is every value expressible in the translated carrier and $\mathcal V\subseteq\mathcal R$ is the image of validated Rust values, the claim is:

not:

That is a boundary to expose, not smooth over.

What remains outside

The formal claims do not prove:

• canonical CBOR decoding or encoding;
• cryptographic signature implementations;
• registry or trust-anchor selection;
• clocks, status stores, replay stores, or budget stores;
• networking or transport;
• credentials and provider effects;
• application adapters; or
• the complete end-to-end verifier control flow.

Those components have other contracts and tests. Pulling them all into one translation would enlarge the trusted and modeled surface while making the central authority theorem harder to inspect. The current boundary follows the decision kernel: validated values enter; an ordered authority decision and, when accepted, an exact transition leave.

The trusted computing base also remains real. It includes Lean’s kernel and the pinned libraries, the pinned Rust/Charon/Aeneas translation semantics, the Rust compiler used for shipping code, the validated-constructor boundary, and the small reviewed external models. Formal verification does not remove trust. It makes the trusted components and the proved relation more precise.

The maintenance property matters most

The most useful outcome is not that the repository contains a formal directory. It is that the relationship among source, translation, semantics, and theorem is executable.

A developer who changes the order of checks in Rust changes an observable diagnostic contract. The source closure and reproduced translation change. The old theorem statement may remain the same, but its proof against the new generated evaluator must still succeed.

A developer who weakens the theorem changes its elaborated statement digest. The assurance audit fails until the public claim is deliberately updated and reviewed.

A developer who introduces an opaque local translation or a new external model violates the qualification inventory. A developer who replaces a proof with sorry introduces sorryAx, which violates the allowed transitive axiom set. A developer who modifies a relevant source through an unrecognized path causes the fail-closed planner to run or reject the formal phase rather than silently skip it.

This is the standard I want from formalization in Auths Proof:

The box is not a claim that every component is proved. It is a claim that, for the named authority kernel and its valid input domain, the connection is specific enough to inspect and strict enough to break.

That last property is what makes the proof part of the software rather than a paper about the software.
